58 MC18 Conveying Screw Element With Vacuum Quenching For Twin Screw Extruder
| Brand Name: | OEM |
| Model Number: | CSE014 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | T/T,WesternUnion,Negotiable |
| Supply Ability: | 8000pcs/month |
58 Conveying Screw Element
,MC18 Conveying Screw Element
,MC18 twin screw extruder elements
58 MC18 Conveying Screw Element with Vacuum Quenching for Twin Screw Extruder
Product Description
The 58 MC18 Conveying Screw Element is designed for twin screw extruder systems and continuous extrusion applications. It provides stable material conveying and helps maintain consistent material flow through the extrusion process.
The screw element uses MC18 material and receives vacuum quenching heat treatment to improve hardness, strength, and wear resistance. This treatment helps the element handle continuous mechanical stress and friction during extrusion.
The precision-machined spline connection allows the screw element to fit the corresponding twin screw shaft. Accurate machining also helps maintain proper alignment between adjacent screw elements during assembly.
The 58 MC18 conveying screw element suits plastic compounding and other extrusion processes. We can manufacture the element according to the customer's extruder model, shaft specification, screw configuration, drawing, or original sample.
Product Specifications
| Item | Specification |
|---|---|
| Product Name | 58 MC18 Conveying Screw Element |
| Product Type | Twin Screw Extruder Screw Element |
| Element Function | Conveying |
| Extruder Type | Co-Rotating Twin Screw Extruder |
| Nominal Diameter | 58 mm |
| Material | MC18 |
| Material Type | High Wear-Resistant Alloy Tool Steel |
| Heat Treatment | Vacuum Quenching |
| Heat Treatment Purpose | Improve Hardness, Strength and Wear Resistance |
| Flight Configuration | According to Screw Design |
| Flight Direction | Right-Hand / Left-Hand |
| Connection Type | Internal Spline |
| Spline Profile | According to Shaft Specification |
| Spline Tolerance | According to Customer Drawing |
| Element Length | According to Customer Requirement |
| Element Geometry | According to Application |
| Dimensional Tolerance | According to Technical Drawing |
| Surface Finish | Precision CNC Machined |
| Hardness | According to Material and Heat Treatment Requirement |
| Wear Resistance | High |
| Corrosion Resistance | According to Processing Conditions |
| Application | Plastic Compounding & Extrusion |
| Compatible Materials | Thermoplastics, Filled Plastics, Engineering Plastics |
| OEM Replacement | Available |
| Customization | Available |
| Quality Inspection | Material, Dimensions, Hardness, Spline & Surface Inspection |
| Packaging | Export Standard Packaging |
Key Features
-
MC18 material
-
Vacuum quenching heat treatment
-
High hardness and wear resistance
-
Precision CNC machining
-
Accurate internal spline
-
Stable material conveying
-
Suitable for continuous extrusion
-
Compatible with customized screw configurations
Applications
The 58 MC18 conveying screw element can support various twin screw extrusion processes, including:
-
Plastic compounding
-
Engineering plastics
-
Filled plastics
-
Masterbatch production
-
Polymer processing
-
Other continuous extrusion applications
Custom Manufacturing
CONLIN can manufacture conveying screw elements in different geometries and materials according to the required working conditions.
Please provide the extruder model, shaft diameter, element dimensions, original part number, or technical drawing when requesting a quotation. We can check the required specifications and provide a suitable screw element solution.
